specification:
| Engine | |
| Brand | Commins |
| Model | QSB7 |
| Cylinder number | 6 |
| Air intake | Turbocharged |
| Rated power/speed | 169kw/2000rpm |
| Emission standard | China three electric spray |
| (rpm)Rotating speed | 12.5 |
| （km/h）Traveling speed | 5.5/3.2 |
| (Kpa)Ground specific voltage | 46 |
| （kN）Bucket digging force | 136.9/144.8 |
| （kN）Arm crowd force | 97.9/103.8 |
Dimension:
| Transportation height(to the top of thearm) | O | (mm) | 3100 |
| Transportation height(to the top of the hose) | P | (mm) | 3180 |
| Transport length | Q | (mm) | 9730 |
| Transport width | Z | (mm) | 3192 |
| Counter weight ground clearance | S | (mm) | 1100 |
| Total high(to the top of the cab) | T | (mm) | 3020 |
| Transit width | U | (mm) | 2800 |
| The height ofthe cab(above the plat form) | V | (mm) | 850 |
| The cab width | W | (mm) | 1000 |
| Guide wheel and drive wheel center distance | X | (mm) | 3680 |
| Track length | Y | (mm) | 4450 |
| Total width | Z | (mm) | 3192 |
| Track width | a | (mm) | 600 |
| Track height | b | (mm) | 960 |
| Mini ground clearance | C | (mm) | 460 |
| Scope of work | |||
| Max digging distance | A | (mm) | 9873 |
| Max digging distance on ground | B | (mm) | 9699 |
| Digging depth | C | (mm) | 6592 |
| Max loading height | D | (mm) | 6830 |
| Mini loading height | E | (mm) | 2501 |
| Digging height | F | (mm) | 9616 |
| Max height of bucketpin | G | (mm) | 8274 |
| Max vertical arm digging depth | H | (mm) | 3929 |
| Max vertical radius | I | (mm) | 7988 |
| 8 feet max digging depth on flatground | J | (mm) | 6411 |
| 8 fee tmini digging radius on flatground | K | (mm) | 2858 |
| Mini digging distance | L | (mm) | 562 |
| Mini turning radius | M | (mm) | 3560 |
| Bucket extension angle | d | ( °) | 178 |
| Tai lturnin gradius | N | (mm) | 2930 |
