specification:
Engine
Brand: ISUZU/CUMMINGS
Model: 6WG1/Q8X15
Cylinder nuber: 6
Air intake: Turbocharged
Emission standard: China three electric spray
Dimension
| Transportation height(to the top of thearm) | O | (mm) | 4885 |
| Transportation height(to the top of the hose) | P | (mm) | 4990 |
| Transport length | Q | (mm) | 12145 |
| Transport width | R | (mm) | 3900 |
| Counter weight ground clearance | S | (mm) | 1430 |
| Total high(to the top of the cab) | T | (mm) | 3420 |
| Transit width | U | (mm) | 3200 |
| The height ofthe cab(above the plat form) | V | (mm) | 1900 |
| The cab width | W | (mm) | 1010 |
| Guide wheel and drive wheel center distance | X | (mm) | 4600 |
| Track length | Y | (mm) | 5695 |
| Total width | Z | (mm) | 3340/3900 |
| Track width | a | (mm) | 600 |
| Track height | b | (mm) | 1230 |
| Mini ground clearance | C | (mm) | 790 |
| Max digging distance | A | (mm) | 11432 |
| Max digging distance on ground | B | (mm) | 11137 |
| Digging depth | C | (mm) | 6975 |
| Max loading height | D | (mm) | 7145 |
| Mini loading height | E | (mm) | 3205 |
| Digging height | F | (mm) | 10710 |
| Max height of bucketpin | G | (mm) | 9190 |
| Max vertical arm digging depth | H | (mm) | 3215 |
| Max vertical radius | I | (mm) | 9840 |
| 8 feet max digging depth on flatground | J | (mm) | 6830 |
| 8 fee tmini digging radius on flatground | K | (mm) | 3720 |
| Mini digging distance | M | (mm) | 5240 |
| Bucket extension angle | d | ( °) | 178 |
| Tai lturnin gradius | N | (mm) | 3960 |
