specification:
Engine
Brand: Yanmar
Model: 4TNV98
Cylinder nuber: 4
Cylinder bore* valve: 94*94*110
Emission standard: China three electric spray
| Dimension | |||
| Transportation height(to the top of thearm) | O | (mm) | 2610 |
| Transportation height(to the top of the hose) | P | (mm) | 2680 |
| Transport length | Q | (mm) | 6030 |
| Transport width | Z | (mm) | 2180 |
| Transit width | U | (mm) | 2130 |
| Guide wheel and drive wheel center distance | X | (mm) | 2110 |
| Track length | Y | (mm) | 2750 |
| Track width | a | (mm) | 450 |
| Track height | b | (mm) | 695 |
| Mini ground clearance | c | (mm) | 370 |
| Max digging distance | A | (mm) | 6270 |
| Max digging distance on ground | B | (mm) | 6115 |
| Digging depth | C | (mm) | 4080 |
| Max loading height | D | (mm) | 5170 |
| Mini loading height | E | (mm) | 2345 |
| Digging height | F | (mm) | 7100 |
| Max height of bucketpin | G | (mm) | 6150 |
| Max vertical arm digging depth | H | (mm) | 2670 |
| Max vertical radius | I | (mm) | 4750 |
| 8 feet max digging depth on flatground | J | (mm) | 3725 |
| 8 fee tmini digging radius on flatground | K | (mm) | 1120 |
| Mini digging distance | L | (mm) | 560 |
| Mini turning radius | M | (mm) | 1745 |
| Tail turning radius | N | (mm) | 1750 |
