Specification:
| Engine | |
| Brand | ISUZU |
| Model | 6HK1 |
| Cylinder number | 6 |
| Air intake | Turbocharged |
| Rated power/speed | 212kw/2000rpm |
| Emission standard | China three electric spray |
| Hydraulic system | |
| Main pump | Kawasaki |
| Performance | |
| (rpm)Rotating speed | 10.6 |
| （kN/m)rotary torque | 96 |
| （km/h）Traveling speed | 5.7/3.2 |
| (Kpa)Ground specific voltage | 58 |
| （kN）Bucket digging force | 189/202 |
| （kN）Arm crowd force | 131/139 |
| Overview |
| Place of origin Yantai CHINA |
| Total weight 33500 |
| Bucket capacity 1.6-1.8m3 |
| Oils capacity |
| (L)Fuel tank 460 |
| (L)Hydraulic tank 295 |
| （L)Engine oil change 42 |
| (L)Heatsink 42 |
Dimensions
| Transportation height(to the top of thearm) | O | (mm) | 3300 |
| Transportation height(to the top of the hose) |
P |
(mm) |
3410 |
| Transport length | Q | (mm) | 11050 |
| Transport width | Z | (mm) | 3285 |
| Counter weight ground clearance | S | (mm) | 1190 |
| Total high(to the top of the cab) | T | (mm) | 3080 |
| Transit width | U | (mm) | 3070 |
| The height ofthe cab(above the plat form) | V | (mm) | 850 |
| The cab width | W | (mm) | 1000 |
| Guide wheel and drive wheel center distance | X | (mm) | 4040 |
| Track length | Y | (mm) | 4910 |
| Total width | Z | (mm) | 3285 |
| Track width | a | (mm) | 600 |
| Track height | b | (mm) | 1090 |
| Mini ground clearance | C | (mm) | 530 |
| Max digging distance | A | (mm) | 10748 |
| Max digging distance on ground | B | (mm) | 10553 |
| Digging depth | C | (mm) | 7320 |
| Max loading height | D | (mm) | 7258 |
| Mini loading height | E | (mm) | 2732 |
| Digging height | F | (mm) | 10243 |
| Max height of bucketpin | G | (mm) | 8885 |
| Max vertical arm digging depth | H | (mm) | 4414 |
| Max vertical radius | I | (mm) | 8567 |
| 8 feet max digging depth on flatground | J | (mm) | 7152 |
| 8 fee tmini digging radius on flatground | K | (mm) | 3084 |
| Mini digging distance | L | (mm) | 360 |
| Mini turning radius | M | (mm) | 4019 |
| Bucket extension angle | d | ( °) | 175 |
| Tai lturnin gradius | N | (mm) | 3500 |
